galvanized coating thickness measurement on rubber material

The N probes measure the thickness of non - magnetic coatings on non - magnetic metals. It is used on anodizing, varnish, paint, enamel, plastic coatings, powder, etc. applied to aluminum, brass, non - magnetic stainless steel, etc.
Quantidade:
  • PH242a
  • Piezohannas
  • PH242a

Features:



Software for PC connection and data analysis.

High quality metal sheel.

With back - light.

Function&Feature:

High stability and precision.

Software for PC connection and data transmission, analysis, and printing measurement reports.

With built - in thermal printer. Width of printer paper: 56.5±0.5mm.

Rechargeable Li - ion battery, available for 10 hours working continuously.

MeasuringMaterials:

MagneticInduction(Fe): Measuring the thickness ofNon - magnetic coating on magneticmetal substrate,such as aluminum, chromium, copper, zinc, rubber, paint on thebase ofsteel, iron, alloy and magnetic steel.

EddyCurrent(NFe): Measuring the thickness ofNon - conductive coating on non - magnetic metal substrate, such as rubber, plastic, paint, oxideon the base ofaluminum, copper, zinc, tin.



MeasuringMaterials:

    MagneticInduction(Fe): Measuring the thickness ofNon - magnetic coating on magneticmetal substrate,

such as aluminum, chromium, copper, zinc, rubber, paint on thebase ofsteel, iron, alloy and magnetic steel.

    EddyCurrent(NFe): Measuring the thickness ofNon - conductive coating on non - magnetic metal substrate, such as rubber, plastic, paint, oxideon the base ofaluminum, copper, zinc, tin.



Technical Specification




Model

PH242a

Measuringprinciple

Magnetic induction(Fe)or Eddy current (NFe)

Measuring range (µm)

0~1250μm

Accuracy

±[1~2%) H+1] μm

H refers tothe thickness of testing piece

Minimumresolution (µm)

0.1μm

Min curvature of the min area (mm)

Convex1.5 Concave9

Diameter of the min area (mm)

Φ7

Critical thickness of substrate (mm)

0.5

Operating temperature

0℃~40℃

Magnetic field

No strong magnetic field environment

Memory

500groups measureddata

Dimensions

230×86×46mm

Weight

400g

Printer

Build - in High - speed Thermal Printer

Power supply

RechargeableLi- ion battery

Standard configuration

Main unit,5 specimens(48.5mm、 99.8mm、 249mm、 513mm

1024mm),Charger, paper for printer, Fe or NFe probe & substrate

Optional Accessories

ProbesSpecimensPaper for printer
